Summary

A highly efficient and talented design engineer with a comprehensive understanding of RF system design processes and also microelectronic fabrication methods. Experienced in all the design stages of a product, including research, development and manufacture right through to evaluation and production release. Possessing a good team spirit, deadline orientated and having the ability to plan parallel projects. Keen to find a challenging & suitable engineering position in filter design with an ambitious company that offers opportunities for career development and advancement, especially in RF.

Overview

20
20
years of professional experience
1
1
Certification

Work History

Senior Staff Engineer

Qualcomm Inc.
11.2021 - Current

Feasibility and design of SAW and BAW filters on modules for cellular RF systems

Key Skills:

  • 14 years of SAW & BAW filter topology experience on different bands from low to ultra high bands, with varying design challenges for small and large signal performance, size & cost.
  • Codesigned with the module team, worked on the laminate section for the acoustic area for optimum performance on impedance match, rejection & isolation & heat dissipation.
  • Experienced on filter codesign for both Tx (load pull, PAE & ACLR, figure of merits and locus size) and Rx (LNA NF & gain)
  • Conducted electromagnetic simulations (HFSS) for loss breakdown and inductor Q improvement and coil sensitivity analysis
  • Power durability & harmonics simulations to ensure large-signal specs compliance

Major accomplishments:

  • BAW B7, B40, B41 codesigned for HB PAMID module meeting targeted IL and critical rejection specs (critical skirt steepness) while keeping smallest BAW size with best layout practices.
  • Lead for BAW n77 & n79 C-Band 5G design experience for both Tx & Rx for a module codesign using non-conventional topologies
  • BAW 6GHz n106 Tx & Rx ultrawide design (1.2 GHz BW) in the smallest die dimensions allowed by fab

Staff Manager/Engineering Manager

Qualcomm Inc.
12.2019 - 11.2021

Staff Engineer

Qualcomm Inc.
01.2019 - 12.2019

Sr RF Filter and Module Design Engineer

Qualcomm Inc.
02.2017 - 12.2018
  • Liaised with stakeholders to define and document design requirements.
  • Brainstormed with product designers to implement and refine new manufacturing processes.
  • Addressed design challenges and evaluated alternative design models to meet project requirements.
  • Conducted technical evaluations of engineering designs and test results.

RF FILTER & MODULE DESIGN ENGINEER

EPCOS, Inc. (TDK)
05.2015 - 02.2017

Feasibility and design of RF SAW filters and modules for wireless communications

Key skills:

  • Achieve desired filter response by selecting appropriate filter design techniques, process and technology nodes
  • Module codesign for optimum performance
  • Feasibility studies, final design and releasing to mass production of SAW RF filters and modules for wireless communications.
  • Running linear and non-linear simulation, EM parasitics evaluation and optimization.

Major Accomplishments:

  • SAW filter designs for B39-B41FB, single B41FB released to production for a leading US customer with high-volume orders
  • SAW HQTCF B30 design for HB-PAMiD designed and released to production.

PRODUCT DEVELOPMENT ENGINEER

Epcos Pte Ltd (A member of TDK Corporation)
11.2011 - 05.2015
  • Responsible for the development of radio frequency surface acoustic wave (SAW) filters for mobile phone applications (GSM, W-CDMA and LTE).
  • Duties:
  • Product definition of filter specifications based from customer requirements.
  • Achieve desired filter response by selecting appropriate filter design techniques, process and technology.
  • Design win: Filter design with temperature-compensation on a 1GHz band with high a relative bandwidth requirement.
  • Filter design in wafer-level packages for modules for a top tier customer.

APPLICATIONS ENGINEER

Arcadia Engineering Pte Ltd
11.2008 - 11.2011
  • Duties:
  • Planning and design of continuous improvement process (CIP) for semiconductor equipment to achieve highest performance and increased reliability.
  • Provide application support to wafer fabrication customers.
  • Support sales team in technical presentations to clients and provide application training.

RF TEST & PRODUCT ENGINEER

NXP Semiconductors (formerly Philips Semiconductors Inc.)
11.2005 - 10.2008
  • Duties:
  • IC test load board design for new RF (GSM, EDGE, CDMA, Wi-Fi, Bluetooth) products.
  • Build test program (C++ and Cadence), debug and qualification.
  • Provided technical support for the production testing of assigned RF products.
  • Project design and implementation to achieve product yield improvements, coordinated with both wafer and IC (back- and front-end) testing.
  • Major Projects:
  • Project: Sample on the Fly (SOTF) on all LTX-tested products thru adaptation of handler-tester communication, tester libraries and test program (C++) to improve output efficiency by conducting simultaneous quality assurance testing with the final testing.

Education

Post Graduate Diploma - Electrical Engineering

University of The Philippines
Republic
01.2006

Bachelor of Science Degree - Electronics and Communications Engineering

Mapua Institute of Technology
01.2004

Skills

  • RF Circuit Design
  • Product Development
  • Acoustic Simulation
  • EM Simulation (HFSS)
  • Wireless & Mobile Products
  • RF Product Testing (ATE)
  • Semiconductor Manufacturing
  • Electronic Design Automation Software
  • CAD/CAE
  • Unix
  • Linux
  • Innovative
  • Focused
  • Generating new ideas
  • Problem solving
  • Excellent organisational skills
  • In-depth understanding of RF systems
  • Skilled in EM simulation using Ansoft’s HFSS software
  • Proficient with electronic design automation software such as Agilent Advanced Design System (ADS), AWR’s Microwave Office and APLAC, and Electronic Workbench
  • Knowledgeable in using test and measurement instruments Vector Network Analyzer, Spectrum Analyzer, Oscilloscope, Signal Generator and Power Meter
  • Adept in using advanced statistical analysis tools to ensure conformance to specifications and manufacturing processes
  • Having the ability to think and create in three dimensions
  • Able to work as part of a team or individually
  • CAD proficient and have good design & technical skills
  • Flexible and willing to travel
  • An ability to withstand a pressured team
  • Ensuring confidentiality at all times
  • Able to communicate effectively both verbally and in writing

Certification

  • Licensed Electronics and Communications Engineer, Board Exams, Philippines April 2005
  • Institute of Electrical and Electronics Engineers (IEEE)

CAREER STATEMENT

“I feel that my three greatest strengths are firstly having the enthusiasm and fascination for leading edge technology in RF especially its applications in mobile communications. Secondly an ability to understand and prioritise my work in a changing business environment, thereby helping me to successfully deliver results. Finally my passion to be involved in challenging design projects that would allow me to utilize and further broaden my technical knowledge in RF design.“
